| Especificações | |
|---|---|
| Data Rate Filter | 100Gbps |
| Data Rate | 111.81Gbps |
| Connector Type | LC/UPC |
| Media Type | SMF |
| Transmitter | EML |
| Receiver | PIN |
| Voltage | 3.3 |
| Distance | 10km |
| RX Overload (dBm) | 4,5 |
| RX Sensitivity (dBm) | -10,6 |
| Temp. | 0 to 70ºC |
| TX Max. (dBm) | 2,9 |
| TX Min. (dBm) | -2,5 |
| Wavelength (nm) | 1310nm |
| Link Budget (dB) | 8,1 |
| Modulation | NRZ |
| Eletrical Lanes | 10 |
| Optical Lanes | 4 |
| Digital Diagnostics (DDM) | Yes |
| Power Consumption | 12 |
