Especificações | |
---|---|
Data Rate Filter | 400Gbps |
Data Rate | 425Gbps |
Connector Type | LC/UPC |
Media Type | SMF |
Transmitter | EML |
Voltage | 3.3 |
Distance | 10km |
RX Overload (dBm) | 5,1 |
RX Sensitivity (dBm) | -9 |
Temp. | 0 to 70ºC ~ -40 to 85°C |
TX Max. (dBm) | 5,1 |
TX Min. (dBm) | -2,7 |
Wavelength (nm) | 1264.5-1337.5 |
Link Budget (dB) | 6,3 |
Modulation | PAM4 |
Eletrical Lanes | 8 |
Optical Lanes | 4 |
Digital Diagnostics (DDM) | Yes |
Power Consumption | <12W |
